• Working Pressure :8-35[ bar ]

• 116-508[ psig ]

• Free Air Delivery :3.2-39[ m3/min ]

• 115-1377[ cfm ]

• Working Power :32-522[ kw ]

• 53-680[ hp ]


  Model		KSTCY- 3.2/8	KSTCY- 5.3/7	KSTCY- 5/10	KSTCY- 6/7	KSTCY- 7.5/7	KSTCY- 8.5/10	KSTCY- 9/7	KSTCY- 10/8	KSTCY- 10/13	KSTCY- 11/10	KSTCY- 11/13	KSTCY- 12/7	KSTCY- 12/10	KSTCY- 12/13
  Machine
  Free Air Delivery	m3/min	3.2	5.3	5	6	7.5	8.5	9	10	10	11	11	12	12	12
  	CFM	115	190	177	212	265	300	318	353	353	388	388	424	424	424
  Normal Working Pressure	bar(e)	8	7	10	7	7	10	7	8	13	10	13	7	10	13
  	psig	116	102	145	102	107	145	102	116	189	145	189	102	145	189
  Weight		1000	1600	1600	1600	1600	1800	1800	1800	2050	2050	3600	2050	2050	2050
  Dimensions（without towbar)	L(mm)	2100	2300	2300	2300	2300	2600	2440	2440	3270	3270	3575	3270	3270	3400
  	W(mm)	1500	1790	1790	1790	1790	1910	1910	1910	1910	1910	1700	1910	1910	1700
  	H(mm)	1360	1580	1580	1580	1580	2015	1920	1920	2080	2080	2320	1950	1950	2320
  Wheel Qty		2	2	2	2	2	2	2	2	2	2	2	2	2	4
  Size * No. of Air Outlet Valve		G 1-1/2 "*1 G 1" *1	G 3/4" *1 G 1-1/4 "*1	G 3/4" *1 G 1-1/4 "*1	G 3/4" *1 G 1-1/4 "*1	G 3/4" *1 G 1-1/4 "*1	G 1" *1 G 1-1/4 "*1	G 1" *1 G 1-1/2 "*1	G 1" *1 G 1-1/2 "*1	G 1" *1 G 1-1/2 "*1	G 1" *1 G 1-1/2 "*1	G 1" *1 G 2-1/2 "*1	G 1" *1 G 1-1/2 "*1	G 1" *1 G 1-1/2 "*1	G 1" *1 G2-1/2 "*1
  Diesel Engine
  Manufacturer		Yangdong	Cummins
  Model		YSD490G	4BT3.9-C80				4BTA3.9-C125	4BT3.9-C100		6BT5.9-C150		6BTA5.9-C180	6BT5.9-C150		6BTA5.9-C180
  Type		Vertical, in-line, Water-cooled, 4-stroke, Direct injection
  Bore*Stroke(mm)*No. of Cylinders		90*100*4	102*120*4	102*120*4	102*120*4	102*120*4	102*120*4	102*120*4	102*120*4	102*120*6	102*120*6	102*120*6	102*120*6	102*120*6	102*120*6
  Engine Speed(nominal)(RPM)		2400	2200	2400	2200	2200	2200	2200	2200	2300	2300	2500	2500	2300	2300
  Engine speed(unloaded)(RPM)		1500	1400	1500	1400	1400	1400	1500	1500	1400	1400	1500	1400	1400	1500
  Rated Power	KW	32	60	60	60	60	93	74	74	110	110	132	112	110	132
  	HP	53	80	80	80	80	125	100	100	150	150	180	150	150	150
  Engine Oil Capacity(L)		6.5	11	11	11	11	12	12	12	14	14	20	14	14	20
  Coolant Capacity(L)		20	25	25	25	25	30	30	30	30	30	50	30	30	50
  Fuel Tank Capacity(L)		55	105	85	105	105	125	100	100	130	130	360	130	130	360
  Storage Battery Voltage and Current		12V75Ah	24V120Ah	24V120Ah	24V120Ah	24V120Ah	24V135Ah	24V135Ah	24V135Ah	24V135Ah	24V135Ah	24V135Ah	24V135Ah	24V135Ah	24V135Ah
  Compressor
  No. of Compression Stage		1	1	1	1	1	1	1	1	1	1	1	1	1	1
  Compressed air vessel capacity(L)		24	43	43	43	43	100	80	80	110	110	190	110	110	190
  Lubricant Capacity(L)		20	30	30	30	30	50	50	50	58	58	80	58	50	80






  Model		GYCY- 13/8	GYCY- 13/13	GYCY- 15.5/10	GYCY- 15/13	GYCY- 15/16	GYCY- 15/18	GYCY- 17/7	GYCY- 17/8	GYCY- 17/13	GYCY- 17/14.5	GYCY- 17/16	GYCY- 18/18	GYCY- 19/14.5
  Machine
  Free Air Delivery	m3/min	13	13	15.5	15	15	15	17	17	17	17	17	18	19
  	CFM	460	460	547	530	530	530	600	600	600	600	600	636	671
  Normal Working Pressure	bar(e)	8	13	10	13	16	18	7	8	13	14.5	16	18	14.5
  	psig	116	189	145	189	232	261	102	116	189	210	232	261	210
  Weight		2050	3600	3600	3600	4000	3500	3600	3600	4000	3500	3500	3300	3300
  Dimensions（without towbar)	L(mm)	3270	3400	3400	3400	3390	3555	3400	3400	3390	3555	3555	4225	4225
  	W(mm)	1910	1700	1700	1700	1700	1750	1700	1700	1700	1750	1750	1980	1980
  	H(mm)	2080	2320	2320	2320	2640	2660	2320	2320	2640	2660	2660	2690	2690
  Wheel Qty		2	4	4	4	4	4	4	4	4	4	4	4	4
  Size * No. of Air Outlet Valve		G1"*1 G1-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G1-1/2"*1	G1"*1 G1-1/2"*1
  Diesel Engine
  Manufacturer		Yangdong	Cummins
  Model		6BT5.9-C150	6BTA5.9-C180			6CTA8.3-C215	6CTA8.3-C260	6BTA5.9-C180		6CTA8.3-C215	6CTA8.3-C260		6LTAA8.9-C325
  Type		Vertical, in-line, Water-cooled, 4-stroke, Direct injection
  Bore*Stroke(mm)*No. of Cylinders		102*120*6	102*120*6	102*120*6	102*120*6	114*135*6	114*135*6	102*120*6	102*120*6	114*135*6	114*135*6	114*135*6	114*145*6	114*145*6
  Engine Speed(nominal)(RPM)		2300	2500	2500	2500	2200	2200	2500	2200	2200	2200	2200	2200	2200
  Engine speed(unloaded)(RPM)		1400	1500	1500	1500	1500	1500	1500	1500	1500	1500	1500	1500	1500
  Rated Power	KW	110	132	132	132	160	194	132	132	160	194	194	239	239
  	HP	150	180	180	180	215	260	180	180	215	260	260	325	325
  Engine Oil Capacity(L)		14	20	20	20	25	25	20	20	25	25	25	28	28
  Coolant Capacity(L)		30	50	50	50	60	75	50	50	60	75	75	55	55
  Fuel Tank Capacity(L)		130	360	360	360	370	390	360	360	370	390	390	590	590
  Storage Battery Voltage and Current		24V135Ah	24V135Ah	24V135Ah	24V135Ah	24V165Ah	24V165Ah	24V135Ah	24V135Ah	24V135Ah	24V165Ah	24V165Ah	24V180Ah	24V180Ah
  Compressor
  No. of Compression Stage		1	1	1	1	1	1	1	1	1	1	1	1	1
  Compressed air vessel capacity(L)		110	190	190	190	180	180	190	190	190	190	180	200	200
  Lubricant Capacity(L)		58	80	80	80	100	120	80	80	100	120	120	110	110






  Model		GYCY- 19/16	GYCY- 20/16	GYCY- 21/8	GYCY- 22/20	GYCY- 22.5/14	GYCY- 25.5/20	GYCY- 27/10	GYCY- 32/10	GYCY- 33/35	GYCY- 34/25	GYCY- 39/25
  Machine
  Free Air Delivery	m3/min	19	20	21	22	22.5	25.5	27	32	33	34	39
  	CFM	671	706	742	777	795	900	953	1130	1165	1200	1377
  Normal Working Pressure	bar(e)	16	16	8	20	14	20	10	10	35	25	25
  	psig	232	232	116	290	203	290	145	145	508	363	363
  Weight		3300	3300	4000	6500	3300	5500	3300	6500	7200	6000	7200
  Dimensions（without towbar)	L(mm)	4225	4225	3390	4700	4225	4750	4225	4700	5000	4510	5000
  	W(mm)	1980	1980	1700	2300	1980	2100	1980	2300	2200	2160	2200
  	H(mm)	2690	2690	2640	2750	2690	2860	2690	2750	3000	3150	2200
  Wheel Qty		4	4	4	4	4	4	4	4	4	4	4
  Size * No. of Air Outlet Valve		G1"*1 G1-1/2"*1	G1"*1 G1-1/2"*1	G1"*1 G2-1/2"*1	G1"*1 G2"*1	G1"*1 G1-1/2"*1	G1-1/2"*1 G2"*1	G1"*1 G1-1/2"*1	G1"*1 G2"*1	G1"*1 G2"*2	G2-1/2"*1	G1"*1 G2"*2
  Diesel Engine
  Manufacturer		Yangdong	Cummins
  Model		6LTAA8.9-C325		6CTA8.3-C215	6LTAA9.5-C360-II	6LTAA8.9-C325	EQR400-K2	6LTAA8.9-C325	6LTAA9.5-C360-II	KTA19-P680	KTA19-C600	KTA19-P680
  Type		Vertical, in-line, Water-cooled, 4-stroke, Direct injection
  Bore*Stroke(mm)*No. of Cylinders		114*145*6	114*145*6	114*135*6	116.5*148*6	114*145*6	123*156*6	114*145*6	116.5*148*6	159*159*6	159*159*6	159*159*6
  Engine Speed(nominal)(RPM)		2200	2200	2200	2200	2200	1900	2200	2200	2200	2200	2200
  Engine speed(unloaded)(RPM)		1500	1500	1500	1500	1500	1300	1500	1500	1500	1500	1500
  Rated Power	KW	239	239	160	264	239	294	239	264	522	448	522
  	HP	325	325	215	360	325	400	325	360	680	600	680
  Engine Oil Capacity(L)		28	28	25	30	28	36	28	30	59	47	59
  Coolant Capacity(L)		55	55	60	65	55	75	55	65	130	130	130
  Fuel Tank Capacity(L)		590	590	370	660	590	640	590	660	700	770	700
  Storage Battery Voltage and Current		24v180Ah	24v180Ah	24v165Ah	24v300Ah	24v180Ah	24v180Ah	24v180Ah	24v300Ah	24v300Ah	24v200Ah	24v300Ah
  Compressor
  No. of Compression Stage		1	1	1	2	1	2	1	1	2	2	2
  Compressed air vessel capacity(L)		220	220	190	135	200	140	220	135	175	158	175
  Lubricant Capacity(L)		110	110	100	115	110	100	110	115	140	120	140
